Description

The operation of this circuit relies primarily on the capabilities of the voltage regulator. The 7809 integrated circuit is capable of supplying up to 2 amperes consistently, whilst simultaneously maintaining a minimal level of disturbance and ensuring a stable power supply. The design functions effectively without the supplemental elements, however, for safeguarding against reversed voltage input, a 1N5400 diode (D1) is incorporated at the input. Furthermore, the output stage utilizes C2 to enhance noise reduction, and if the circuit is intended to power a digital logic system, a 100nF (C3) ceramic or polyester capacitor is recommended to eliminate any high-frequency switching interference.

Circuit diagram:

Parts:

7809 Positive Voltage Regulator IC

The 7809 is a three-terminal positive voltage regulator IC. It’s a common choice for generating a stable 5V DC supply from a higher voltage source. This integrated circuit operates with a fixed current limit of 2 amps, providing a regulated output despite variations in the input voltage or load current. It utilizes internal feedback circuitry to maintain a constant output voltage, making it suitable for powering sensitive electronic circuits. It typically includes thermal shutdown protection to prevent overheating.

1N5400 Diode

The 1N5400 is a silicon signal diode. It’s a general-purpose diode frequently utilized for rectification, reverse voltage protection, and signal isolation. This diode offers a fast switching speed and a relatively low forward voltage drop, making it suitable for a wide variety of electronic applications. Its specifications include a reverse voltage rating of 100V and a peak reverse current rating of 1A. It's a dependable choice for basic protection circuits.
